WILDEN   P25 bolt plastic pneumatic separator  membrane pump

WILDEN   P25 bolt plastic pneumatic diaphragm pump specifications:

Material of liquid contact:

Polypropylene transport weight: 2 kg (4 lbs)

Polyvinylidene Fluoride transport weight: 2 kg (4 lbs)

Elastomer material:

Teflon PTFE

Non-liquid-to-liquid material:

Intermediate part: polypropylene;

Air valve: polypropylene;

Performance parameters of WILDEN Wilton P25 bolt plastic pneumatic diaphragm pump:

Media import dimensions: 1/4” (6 mm);

Media outlet dimensions: 1/4” (6 mm);

Air inlet size: 1/8” (3 mm);

Maximum outlet pressure: 8.6 Bar (125 psig);

The maximum solid particle diameter can be passed: 3/32” (0.7mm);

Maximum traffic:

Teflon PTFE: 16.7 lpm (4.4 gpm);

Maximum suction range: Teflon PTFE: dry suction 1.9 m (6.2’), wet suction 9.3 m (30.6’);
