WILDEN Wilton PX1500 bolted stainless steel pneumatic diaphragm pump specifications:
Material of liquid contact:
316 stainless steel transportation weight: 125 kg (275 lbs)
Hastelloy Transport Weight: 130 kg (287 lbs)
Elastomer material:
Nitrile rubber, ternary rubber, SaniflexTM, neoprene, polyimine esters,
Teflon PTFE, fluorinated rubber, Wil-FlexTM.
Non-liquid-to-liquid material:
Air chamber: aluminum alloy, stainless steel;
Middle part: aluminum alloy, stainless steel, polypropylene;
Air valve: aluminum alloy, stainless steel, polypropylene;
Performance parameters of WILDEN Wilton PX1500 bolted stainless steel pneumatic diaphragm pump:
Media import dimensions: 3” (76 mm)
Media outlet dimensions: 3” (76 mm)
Air inlet size: 3/4” (19 mm)
Maximum outlet pressure: 8.6 Bar (125 psig)
Maximum solid particle diameter can be passed: 3/8” (9.5mm)
Maximum traffic:
Rubber/thermoplastic compound: 918 lpm (243 gpm)
Teflon PTFE: 727 lpm (192 gpm)
Maximum suction range: Rubber/thermoplastic compound: dry
suction 6.7 m (22.1’), wet suction 9.5 m (31.2’)
Teflon PTFE: Dry suction 4.9 m (15.9’), wet suction 9.5 m (31.2’
| WILDEN Pump Description | PX1500/AAAAA/VTU/VT/STF |
|---|---|
| Port Size | 3" |
| Air Kit | 15-9988-99 |
| Wet Kit | 15-9814-53-212 |
| Air Distribution System | Pro-Flo X™ |
| Pump Construction | Aluminum |
| Diaphragms | Viton Ultraflex |
| Valve/ Balls | Viton |
| Valve Seats | SS with Teflon O-ring |
| Outer Piston | Aluminum |
| Air Chamber | Aluminum |
| Center Block | Aluminum |
| Air Valve | Aluminum |
| Capacity GPM | 250 |
| Capacity Liters/min | 950 |
| Pump Weight Lbs | 223,0 |
| Pump Weight Kilo | 101 |
| Specialty Code | #N/A |
