WILDEN  PX400 stainless steel bolted pneumatic diaphragm pump

WILDEN   PX400 stainless steel bolted pneumatic diaphragm pump specifications:

Material of liquid contact:

316 stainless steel transportation weight: 43 kg (94 lbs)

Hastelloy Transport Weight: 45 kg (100 lbs)

Elastomer material:

Nitrile rubber, ternary rubber, SaniflexTM, Teflon PTFE, fluorinated rubber, Wil-FlexTM.

Non-liquid-to-liquid material:

Air chamber: aluminum alloy, stainless steel;

Middle part: polypropylene, aluminum alloy, stainless steel;

Air valve: polypropylene, aluminum alloy, stainless steel;

Performance parameters of WILDEN Wilton PX400 stainless steel bolted pneumatic diaphragm pump:

Media import dimensions: 1-1/2” (38 mm)

Media outlet size: 1-1/2” (38 mm)

Air inlet size: 3/4” (19 mm)

Maximum outlet pressure: 8.6 Bar (125 psig)

Maximum solid particle diameter can be passed: 3/16” (4.8 mm)

Maximum traffic:

Rubber/thermoplastic compound: 347 lpm (92 gpm)

Teflon PTFE: 327 lpm (87 gpm)

Maximum suction range: Rubber/thermoplastic compound: dry suction 6.9 m (22.7’), wet suction 9.3 m (30.6’)

Teflon PTFE: Dry suction 4.0 m (13.1’), wet suction 9.0 m (29.5’)
