American WILDEN PX20 series clamp metal pneumatic diaphragm pump

WILDEN  PX20 clamp type metal pneumatic diaphragm pump specifications:

Material of liquid contact:

Ductile iron transport weight: 223 kg (492 lbs);

Elastomer material:

Nitrile rubber, ternary rubber, SaniflexTM, neoprene, polyimine esters, fluorinated rubber, Wil-FlexTM.

Non-liquid-to-liquid material:

Air chamber: aluminum alloy, ductile iron;

Intermediate part: aluminum alloy, polypropylene;

Air valve: aluminum alloy, polypropylene;

Performance parameters of WILDEN Wilton PX20 clamp type metal pneumatic diaphragm pump:

Media import dimensions: 4” (102 mm);

Media outlet dimensions: 4” (102 mm);

Air inlet size: 3/4” (19 mm);

Maximum outlet pressure: 8.6 Bar (125 psig);

Maximum solid particle diameter can be passed: 1-3/8” (35 mm);

Maximum traffic:

Rubber/thermoplastic compound: 1211 lpm (320 gpm);

Maximum suction range:

Rubber/thermoplastic compounds: dry suction 4.3 m (14.1’), wet suction 8.6 m (28.4’);
