WILDEN  PX800 Bolt Plastic Pneumatic Diaphragm Pump

WILDEN  PX800 bolted plastic pneumatic diaphragm pump specifications:

Material of liquid contact:

Polypropylene transport weight: 33 kg (70 lbs);

Polyvinylidene Fluoride transport weight: 45 kg (99 lbs);

Elastomer material:

Nitrile rubber, ternary rubber, SaniflexTM, neoprene, polyimine esters, Teflon PTFE, fluorinated rubber, Wil-FlexTM;

Non-liquid-to-liquid material:

Air chamber: polypropylene;

Intermediate part: polypropylene, aluminum alloy;

Air valve: polypropylene, aluminum alloy;

Performance parameters of WILDEN Wilton PX800 bolted plastic pneumatic diaphragm pump:

Media import dimensions: 2” (51 mm);

Media outlet dimensions: 2” (51 mm);

Air inlet size: 3/4” (19 mm);

Maximum outlet pressure: 8.6 Bar (125 psig);

The maximum solid particle diameter can be passed: 1/4” (6.4mm);

Maximum traffic:

Rubber/thermoplastic compound: 693 lpm (183 gpm);

Teflon PTFE: 579 lpm (153gpm);

Maximum suction range:

Rubber/thermoplastic compounds: dry suction 6.1 m (20.0’), wet suction 9.0 m (29.5’);

Teflon PTFE: dry suction 4.5 m (14.8’), wet suction 7.2 m (23.8’);
