WILDEN  P800 bolt metal pneumatic diaphragm pump

WILDEN Wilton P800 bolt metal pneumatic diaphragm pump specifications:

Material of liquid contact:

Aluminum alloy transport weight: 34 kg (75 lbs)

316 stainless steel transportation weight: 100 kg (200 lbs)

Hastelloy Transport Weight: 103 kg (228 lbs)

Elastomer material:

Nitrile rubber, ternary rubber, SaniflexTM, neoprene, polyimine esters,

Teflon PTFE, fluorinated rubber, Wil-FlexTM.

Non-liquid-to-liquid material:

Air chamber: aluminum alloy, stainless steel;

Intermediate part: polypropylene;

Air valve: polypropylene;

Performance parameters of WILDEN Wilton P800 bolt metal pneumatic diaphragm pump:

Media import dimensions: 2” (51 mm)

Media outlet size: 2” (51 mm)

Air inlet size: 1/2” (13 mm)

Maximum outlet pressure: 8.6 Bar (125 psig)

Maximum solid particle diameter can be passed: 1/4” (6.4mm)

Maximum traffic:

Rubber/thermoplastic compound: 591 lpm (156 gpm)

Teflon PTFE: 496 lpm (131 gpm)

Maximum suction range: Rubber/thermoplastic compound: dry suction 7.0 m (23.0’),

wet suction 9.5 m (31.0’)

Teflon PTFE: Dry suction 4.6 m (15.0’), wet suction 9.5 m (31.0’)
